PanoTools Meeting 2010 Group Shot

This panorama has been stitched from two images taken with the Sony NEX5 camera. I used the so called “Sweep Panorama” shooting mode of the camera. You start to shoot while turning around. The camera takes images very fast and stitches them directly in the camera. The result is a single JPG image. In this case I had to take two panoramas, each with a resulting size of 12416×1856 pixels. Afterwards I used PTGui Pro to combine the two images, which had a horizontal FOV of about 207¬į. The final stitched panorama had a size of 21748×1776 pixels. One problem was moving people, like e.g. Bernhard. I was not able to correct this, because the error already occured inside the camera. Thus the source image for my panorama already had this error. ūüôĀ

Note: This is the very first panorama I took with this new technique!

Geotag Icon Show on map

Related Posts
Experiments with creating a cinemagraph.

Experimenting With a Cinemagraph
READ MORE
This panorama has been made from inside the head of Bavaria. Bavaria is a hollow bronze statue that can be ascended in the inside.

READ MORE
Due to the increasing distribution of cell phones most people don't need telephone booths any more. Being a common mean of communication just 30 years ago, nowadays the telephone booths are mostly waiting to be used..

READ MORE
This panorama shows a view in the harbour of Plymouth.
READ MORE
This article presents a solution to the problem that the IR shutter mode of the Sony NEX 5 can't be combined with other shutter modes like bracketing. An arduino board with a servo is used to release the camera via the normal shutter button.


READ MORE
This panorama has been stitched from 6 handheld shots with the innovative Sony ILCE-QX1 'camera'.


READ MORE
This panorama shows Bad Hindelang from the mountain station of the Imberger Horn cable car.


READ MORE
This is a Pecha Kucha presentation about reprojecting equirectangular images.

READ MORE
In 2012 the German Unity Day has been celebrated in Munich. The celebrations include a showcase of the German federated states (Bundesländer) and also other institutions like the parties of the Bavarian parliament. In the courtyard of the Bavarian Ministry of the Interior was an exhibition showing the many task of the ministry. This image shows a reprojected version of a panorama I made in the courtyard.


READ MORE
The Novoflex NEX/NIK adapter makes it possible to mount Nikon lenses on the Sony NEX camera line.

Nikon Nikkor 20mm f/2.8 AI-s on a Novoflex NEX/NIK Adapter
READ MORE
Experimenting With a Cinemagraph
Oktoberfest like Bavaria sees it
Inside a Forgotten Telephone Booth
Plymouth Harbour Fish Sculpture Shadow
Remote Trigger with Arduino
Court House Courtyard
Bad Hindelang Winter Panorama
Reprojecting equirectangular images, examples
Reprojected Bavarian Ministry of the Interior Courtyard
Nikon Nikkor 20mm f/2.8 AI-s and Novoflex NEX/NIK

Author: PanoTwin Markus

PanoTwin Markus ‚Üí My images on Google Maps

3 thoughts on “PanoTools Meeting 2010 Group Shot”

  1. Hi,
    I left a message on the PTGui group. I don’t know if it got to you. I was trying to do a simple cylindrical stitch like you did above. I used PTGui but got terrible results. can you tell me what settings you used. Your panorama you made with 1 horizontal row of shots, 2 shot of about 207 degrees FOV each. I would like to use my camera in portrait mode which would require 3 shots.
    Any advice?
    thanks,

    Huck

    1. Hi Huck,

      the project contains the two source images with a lens type cylindrical. I made only two control points between the images. One on each of the two borders. I made five additional control points of type vertical line. The optimizer was set to optimize the Field of View, and all Roll, Pitch and Yaw angles.

      I uploaded a very low quality version of the two images (but with the original pixel dimensions) and my PTGui project:
      Project, Image 1, Image 2

      Hope this helps!
