I took this panorama with a new double monopod construction. From the distance it is similar to the one you see here. This is also the first night shot with the new Sony ILCE-7 and the Walimex 8mm/f2.8 fisheye lens. I’m quite pleased with the results!
This is the first pole panorama I shot with the Sony ILCE-7 camera and the Walimex Pro 8mm fisheye lens. In order to use this lens on the camera I had to remove the sun shade. However this was quite easy, as it is made from plastic. I was able to remove it using a small side cutter and a cardboard cutter.
Show on map
Camera Maker: SONY
Camera Model: ILCE-7
Exposure Time (sec): 1/320
Focal Length (mm): 8
Lens: Walimex 8mm/2.8
In a recent article I described, why the E-mount of the Sony ILCE-7 is so interesting for people with legacy lenses and how to configure your Sony ILCE-7 to assist when taking pictures with these lenses. In another article I also described, how to get rid of the magenta cast in the corners when you are using ultra wide lenses on the cameras which incorporate the Sony E-mount.
And here is another example of a legacy ultra wide lens adapted to the E-mount.
Originally this lens was constructed for the M39 screw-mount of early Leica cameras. So you could either use an Novoflex NEX/LEI adapter or you use an M-Bayonet Adapter and the Novoflex NEX/LEM adapter. Depending on your other lenses one of this options should suit your needs. Personally I use the second option and I don’t have any problems while focusing.
If you’d like to read an intensive review of the lens then take a look at this page.
The lens mount of the Sony NEX camera system is called E-mount. The E stands for Eighteen, as the flange focal distance of the Sony NEX camera series is exactly eighteen millimeters. Most interchangeable lens systems use a longer flange focal distance and therefore you can adapt nearly every available lens to the E-mount of the Sony NEX camera system.
You must be aware that this combination only allows manual control. But the Sony A7 (ILCE-7) camera assists in the use of manual lenses if the camera is proper configured:
Make sure you enable the shooting without a lens: Menu → Custom Settings (gear icon) → 3 → Release w/o Lens → Enable
Set the Focus Magnification Time using Menu → Custom Settings (gear icon) → 1 → Focus Magnif. Time → No Limit You can choose between No Limit — 2 Sec — 5 Sec.
Set the Peaking Level using Menu → Custom Settings (gear icon) → 2 → Peaking Level → Mid
You can choose between Low — Mid — High.
Set the Peaking Level using Menu → Custom Settings (gear icon) → 2 → Peaking Color → Yellow
You can choose between Yellow — Red — White.
Switch your camera to A- Mode (aperture priority) and use the Focus Magnifier function to get a perfectly sharp picture even when shooting a fast lens wide open. The default configuration of the camera assigns the Focus Magnifier function to button C1 (Custom Button 1). You can reassign the function using Menu → Custom Settings (gear icon) → 6 → Custom Key Settings.
This image is a panorama in rectilinear projection. It’s stitched from 12 images in two rows. Final size is about 14.000 x 8.000 pixel. I didn’t use a panoramic head, but as the nearest object was nearly 200 meters away I had no issues with parallax errors.
Show on map
Camera Maker: SONY Camera Model: SLT-A99 Exposure Time (sec): 1/640 F-Number: 7.1 Focal Length (mm): 100 Lens: Minolta 100mm/2.8 (Macro) ISO: 100
