This image is a panorama in rectilinear projection. It’s stitched from 12 images in two rows. Final size is about 14.000 x 8.000 pixel. I didn’t use a panoramic head, but as the nearest object was nearly 200 meters away I had no issues with parallax errors.
These two reprojected spherical panoramas originated from this panorma. The first one shows the classic little planet reprojection, the second one a little tunnel reprojection.
Städel Museum Frankfurt Courtyard Little Planet ReprojectionStädel Museum Frankfurt Courtyard Tunnel Reprojection Show on map
Today I received my Sony adapter LA-EA4 and did a quick comparison with the older version LA-EA2. Both adapters add a translucent mirror to a NEX series camera and are built for the Alpha lens lineup. But the newer version LA-EA4 can also be used on the two new mirrorless full-frame sensor cameras with interchangeable lenses from Sony (the Sony A7r and Sony A7). The older version is only suitable for the Sony NEX series with APS-C sized sensors.
There is only a slight difference in weight (Sony LA-EA2 is 200g, the Sony LA-EA4 is 160g). Another difference is of course the size of the translucent mirror. The difference can easily be seen in the product shots. The speed of the autofocus seems to be the same (but I did no scientific test on that).
Both adapters work with the old “screwdriver” type autofocus lenses (Minolta 28-70/2.8 tested) and with the new SSM type autofocus lenses (Sony 70-200/2.8 tested). I did not test any SAM lenses. Both adapters work with my NEX-5 and also with the NEX-7.
With the NEX-5 I could only select a specific autofocus point with the old adapter. With the NEX-7 I could select a specific autofocus point with both adapters.
Sony LA-EA4 boxSony LA-EA4 and casingSony LA-EA4 (left) and Sony LA-EA2 (right)Sony LA-EA4 (left) and Sony LA-EA2 (right)Sony LA-EA4 (left) and Sony LA-EA2 (right)Sony LA-EA4 (left) and Sony LA-EA2 (right)
In a previous article I already described how to post-process images which were taken with ultra wide legacy lenses on a Sony NEX in order to eliminate the magenta cast in the corners. I use the free software cornerfix (which is available for Mac and PC).
In order to get the best results, you should create your own lens profiles. Therefore you can follow these instructions. I recommend a flat field reference file which is based on a picture through a matted glass panel.
But as you may not have such a glass panel at hands you can also download one of my profiles and give it a try.
Here is an example of an uncorrected shot with the Sony NEX-7 and the Leica Summicron 35mm/2 @ f7.1. Uncorrected example image taken with NEX-7 and the Leica Summicron 35mm/2 @ f7.1.
This is the same image but additionally corrected with cornerfix and this profile (5.6). With cornerfix corrected example image taken with NEX-7 and the Leica Summicron 35mm/2 @ f7.1.
This image is a panoramic image in rectilinear projection. It’s stitched from 3 images in landscape orientation. Each of the images was taken with a neutral density filter (10 f-stops) to get an exposure time of 15 seconds.
Long time exposure (15 sec) of Svartifiss (Iceland).
